Adjustable Structural Supports Since 1951.

Mini Screw Jack

$69.58
per MJ-3

Our shortest adjustable Support Jack. The Ellis Mini Jacks are offered in two sizes, with minimum heights of either 6.5" (MJ-3) or 9.5" (MJ-6) and 15,000 lbs. of safe load capacity.

Availability: In Stock


Item #

range of adjustment

safe load capacity

Weight

Price

MJ-3

6.5" to 9"

15,000

10 lb

$69.58

MJ-6

9.5" to 15"

15,000

11 lb

$86.97


share:

Product Overview


Our shortest adjustable Support Jack. The Ellis Mini Jacks are offered in two sizes, with minimum heights of either 6.5" (MJ-3) or 9.5" (MJ-6) and 15,000 lbs. of safe load capacity.



Demonstration Video



Specifications

Ellis Mini Jack 2.5" Adj. (MJ-3)
Load Capacity:
15,000 Lbs / 7.5 Tons (Includes 2.5 to 1 Factor of Safety)
Overall Height Screwed Down:
6-1/2"
Overall Height Fully Extended:
9"
Base Plate:
4" Sq.
Top Plate:
4" Sq. (Swivels Independently from Screw)
Acme Screw Size:
1-1/4"
Range of Adjustment:
2.5"
Lifting Capacity:
3,000 LBS. w/ 12" turning bar (MJ-TB12).
Safety Lock Set Screw: Included


Ellis Mini Jack 5.5" Adj. (MJ-6)
Load Capacity:
15,000 Lbs / 7.5 Tons (Includes 2.5 to 1 Factor of Safety)
Overall Height Screwed Down:
9-1/2"
Overall Height Fully Extended:
15"
Base Plate:
4" Sq.
Top Plate:
4" Sq. (Swivels Independently from Screw)
Acme Screw Size:
1-1/4"
Range of Adjustment:
5.5"
Lifting Capacity:
3,000 LBS. w/ 12" turning bar (MJ-TB12).
Safety Lock Set Screw: Included



*Make adjustments to the height of the Mini Jack by turning the turning wheel. A 3/4" round rod can be used for extra leverage (MJ-TB12). Top plate will swivel independently from the screw.

*Mini Jacks should be attached to a flat solid foundation and should not be subject to any lateral force. Mini Jacks should be used to support straight vertical loads only. We recommend tightening set screw in the side of the 4 hole nut with 6mm allen wrench prior to loading (unless lifting). Before construction begins it is recommended that you consult with certified engineer for approval of our products within your application.  Do not extend screw past advertised adjustment range.  Do not exceed max safe load capacity.


Detailed Product Drawings

MJ-3
MJ-6
